| Sipariş No | Kompactset | Nutring | Ön Bas. Ring | Toz Keçe | Oring | D | D1 | D2 | D3 | L1 | L2 | L3 | L4 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ÇLS-32010 | 30x35x15 | 30x40x8 | - | 30x38x5/7 | 41x4 | 56 | 45 | 31 | 50 | 12 | 8 | 52 | 8 |
| ÇLS-32020 | 40x45x15x3 | 40x50x10 | - | 40x48x5/7 | 56x4 | 71 | 60 | 41 | 63 | 15 | 12 | 68 | 10 |
| ÇLS-32030 | 45x50x15x3 | 45x55x10 | - | 45x55x5/7 | 56x4 | 71 | 60 | 46 | 63 | 15 | 12 | 68 | 10 |
| ÇLS-32040 | 40x45x15x3 | 40x50x10 | 40x55.5x6.3 | 40x48x5/7 | 62x4 | 81 | 70 | 41 | 70 | 15 | 12 | 68 | 10 |
| ÇLS-32050 | 45x50x15x3 | 45x55x10 | 45x60.5x6.3 | 45x55x5/7 | 62x4 | 81 | 70 | 46 | 70 | 15 | 12 | 68 | 10 |
| ÇLS-32060 | 50x55x15x3 | 50x60x10 | - | 50x60x5/7 | 62x4 | 81 | 70 | 51 | 70 | 15 | 12 | 68 | 10 |
| ÇLS-32070 | 55x60x15x3 | 55x65x10 | - | 55x65x5/7 | 62x4 | 81 | 70 | 56 | 70 | 15 | 12 | 68 | 10 |
| ÇLS-32080 | 40x45x15x3 | 40x50x10 | 40x55.5x6.3 | 40x48x5/7 | 73x4 | 91 | 75 | 41 | 80 | 15 | 12 | 68 | 10 |
| ÇLS-32090 | 45x50x15x3 | 45x55x10 | 45x60.5x6.3 | 45x55x5/7 | 73x4 | 91 | 75 | 46 | 80 | 15 | 12 | 68 | 10 |
| ÇLS-32100 | 50x55x15x3 | 50x60x10 | 50x65.5x6.3 | 50x60x5/7 | 73x4 | 91 | 75 | 51 | 80 | 15 | 12 | 68 | 10 |
| ÇLS-32110 | 55x60x15x3 | 55x65x10 | 55x70.5x6.3 | 55x65x5/7 | 73x4 | 91 | 75 | 56 | 80 | 15 | 12 | 68 | 10 |
| ÇLS-32120 | 60x65x15x3 | 60x70x10 | - | 60x70x5/7 | 73x4 | 91 | 75 | 61 | 80 | 15 | 12 | 68 | 10 |
| ÇLS-32130 | 40x45x15x3 | 40x50x10 | 40x55.5x6.3 | 40x48x5/7 | 82x4 | 100 | 85 | 41 | 90 | 15 | 12 | 68 | 10 |
| ÇLS-32140 | 45x50x15x3 | 45x55x10 | 45x60.5x6.3 | 45x55x5/7 | 82x4 | 100 | 85 | 46 | 90 | 15 | 12 | 68 | 10 |
| ÇLS-32150 | 50x55x15x3 | 50x60x10 | 50x65.5x6.3 | 50x60x5/7 | 82x4 | 100 | 85 | 51 | 90 | 15 | 12 | 68 | 10 |
| ÇLS-32160 | 55x60x15x3 | 55x65x10 | 55x70.5x6.3 | 55x65x5/7 | 82x4 | 100 | 85 | 56 | 90 | 15 | 12 | 68 | 10 |
| ÇLS-32170 | 60x65x15x3 | 60x70x10 | 60x75.5x6.3 | 60x70x5/7 | 82x4 | 100 | 85 | 61 | 90 | 15 | 12 | 68 | 10 |
| ÇLS-32180 | 65x70x15x3 | 65x75x10 | 65x80.5x6.3 | 65x/75x5/7 | 82x4 | 100 | 85 | 66 | 90 | 15 | 12 | 68 | 10 |
| ÇLS-32190 | 70x75x15x3 | 70x80x12 | - | 70x80x5/7 | 82x4 | 100 | 85 | 71 | 90 | 15 | 12 | 68 | 10 |
| ÇLS-32200 | 50x55x15x3 | 50x60x10 | 50x65.5x6.3 | 50x60x5/7 | 92x4 | 110 | 95 | 51 | 100 | 15 | 12 | 68 | 10 |
| ÇLS-32210 | 55x60x15x3 | 55x65x10 | 55x70.5x6.3 | 55x65x5/7 | 92x4 | 110 | 95 | 56 | 100 | 15 | 12 | 68 | 10 |
| ÇLS-32220 | 60x65x15x3 | 60x70x10 | 60x75.5x6.3 | 60x70x5/7 | 92x4 | 110 | 95 | 61 | 100 | 15 | 12 | 68 | 10 |
| ÇLS-32230 | 65x70x15x3 | 65x75x10 | 65x80.5x6.3 | 65x/75x5/7 | 92x4 | 110 | 95 | 66 | 100 | 15 | 12 | 68 | 10 |
| ÇLS-32240 | 70x75x15x3 | 70x80x12 | 70x85.5x6.3 | 70x80x5/7 | 92x4 | 110 | 95 | 71 | 100 | 15 | 12 | 68 | 10 |
| ÇLS-32250 | 75x80x15-3 | 75x85x12 | 75x90.5x6.3 | 75x87x7/12 | 92x4 | 110 | 95 | 76 | 100 | 15 | 12 | 68 | 10 |
| ÇLS-32260 | 80X85X15X3 | 80x90x12 | 80x95.5x6.3 | 80x92x7/12 | 92X4 | 110 | 95 | 81 | 100 | 15 | 12 | 68 | 10 |
| ÇLS-32270 | 50x55x15x3 | 50x60x10 | 50x65.5x6.3 | 50x60x5/7 | 102x4 | 125 | 105 | 51 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32280 | 55x60x15x3 | 55x65x10 | 55x70.5x6.3 | 55x65x5/7 | 102x4 | 125 | 105 | 56 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32290 | 60x65x15x3 | 60x70x10 | 60x75.5x6.3 | 60x70x5/7 | 102x4 | 125 | 105 | 61 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32300 | 65x70x15x3 | 65x75x10 | 65x80.5x6.3 | 65x/75x5/7 | 102x4 | 125 | 105 | 66 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32310 | 70x75x15x3 | 70x80x12 | 70x85.5x6.3 | 70x80x5/7 | 102x4 | 125 | 105 | 71 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32320 | 75x80x15-3 | 75x85x12 | 75x90.5x6.3 | 75x87x7/12 | 102x4 | 125 | 105 | 76 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32330 | 80x85x15x3 | 80x90x12 | 80x95.5x6.3 | 80x92x7/12 | 102x4 | 125 | 105 | 81 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32340 | 85x90x15-3 | 85x95x12 | 85x100.5x6.3 | 85x97x7/12 | 102x4 | 125 | 105 | 86 | 110 | 15 | 12 | 68 | 10 |
| ÇLS-32350 | 60x65x15x3 | 60x70x10 | 60x75.5x6.3 | 60x70x5/7 | 108x4 | 125 | 105 | 61 | 115 | 15 | 12 | 68 | 10 |
| ÇLS-32360 | 65x70x15x3 | 65x75x10 | 65x80.5x6.3 | 65x/75x5/7 | 108x4 | 125 | 105 | 66 | 115 | 15 | 12 | 68 | 10 |
| ÇLS-32370 | 70x75x15x3 | 70x80x12 | 70x85.5x6.3 | 70x80x5/7 | 108x4 | 125 | 105 | 71 | 115 | 15 | 12 | 68 | 10 |
| ÇLS-32380 | 75x80x15-3 | 75x85x12 | 75x90.5x6.3 | 75x87x7/12 | 108X4 | 125 | 105 | 76 | 115 | 15 | 12 | 68 | 10 |
| ÇLS-32390 | 80x85x15x3 | 80x90x12 | 80x95.5x6.3 | 80x92x7/12 | 108x4 | 125 | 105 | 81 | 115 | 15 | 12 | 68 | 10 |
Araç Üstü Mobil Vinç Uzatma Kepleri (Dıştan Somunlu)
